•  1/2-rack Frame
• Auto scan & ACT-function
• LED Display
• 16 Preset Channels

Matching ACT-707HE handheld or ACT-707TE body pack transmitters.

UHF Duel-Channel Diversity Receiver

• 1-rack Frame
• Auto scan & ACT-function
• LED Display
• Dual 16 Preset Channels

UHF Single-Channel Diversity Receiver

• 1/2-rack Frame
• Auto scan & ACT-function
• Colour LCD Panel
• 100 Preset Channels

UHF Duel-Channel Diversity Receiver

• 1-rack Frame
• Auto scan & ACT-function
• Colour LCD Panel
• Dual 100 Preset Channels

Matching ACT-707H and ACT-707HM handheld or ACT-707T and ACT-707TM body pack transmitters.

UHF 4-Channel Diversity Receiver

• 4-Channel Frame
• Auto scan & ACT-Function
• Colour LCD Panel
• PC-control of 64 channels

Matching ACT-707H and ACT-707HM handheld or ACT-707T and ACT-707TM body pack transmitters.

ACT-707M UHF Colour LCD Module

• Colour LCD panel has bright and clear displays.
• First in the market to introduce hot-swappable modular design allows quick and direct installation to ACT-707 mainframe and immediate use. Ensures easy operating, servicing, renew and upgrade flexibility.
• Advance computer software. Includes full spectrum analysis and individual channel signal management and monitoring.
• Access to nearly 1,000 frequencies, 9 pre-set groups in each 24MHz band.
• Advanced design in spurious emission shielding; ultra high sensitivity; extreme low noise & spurious emission.

Standard Handheld Transmitter

• Plastic Housing
• Power switch is located on the housing for easy operation.
• LED panel displays power on/off and battery fuel gauge
• Exclusive colour rear cap is available in 10 colours for channel identification.
• Fine-crafted and ergonomically designed housing presents MIPRO's unique style.
• The hypercardioid condenser microphone capsule is ideal for vocal, providing high fidelity, wide frequency response, high dynamic range, rapid transient response, low echo feedback, clarity and accuracy sound image contributes the best sound quality in the digital audio age.
• Patented modularized capsule design provides extremely low handling-noise feature that other brands cannot compete.
• Unique dual steel microphone head-grille design eliminates pop & wind noises and prevents worsening of high pitch loss and directionality.
• Interchangeable microphone capsules are avaliable. A condenser or dynamic capsule to suit personal preference.
• World's first ACT (Automatic Channel Targeting) function provides rapid and automatic channel setting of the transmitter.
• High fidelity modulation circuitry is capable of accepting high input level and less distortion.
• Advanced efficient transmitting and low power consumption circuit design provides battery operating hours 2~3 times longer than other brands.
• Professional quality ensures no impact-damage.

Premium Handheld Transmitter

• World's first ACT-technology. Once you press the [ACT] key on the receiver panel, the transmitter channel is rapidly and automatically locked to the receiver.
• Maximum 148db SPL is achieved by the proprietary "Photo-cell Coupling" high dynamic range modulation circuitry.
• Advanced efficient transmitting and low power consumption circuitry design with 2 AA batteries provides long operating hours.
• LCD panel displays group, channel, error code and battery meter status simultaneously.
• Integrated antenna, fine-crafted and ergonomically-designed housing.
• Extremely low handling-noise feature leads the competitors.
• Detachable upper microphone grille designs for easy after sales services and replacement.
• Unique dual steel microphone head-grille design for anti-pop noise, suffers no impact damage when dropped.
• The supercardioid vocal capsule with high fidelity, wide frequency response, high dynamic range, and transient response contributes the best sound quality in the digital audio age.

Professional Handheld Transmitter

Innovative Features
Professional audio engineers have their own microphone sound preferences via knowledge and experience and will not select simply based on name brands only. MIPRO handheld transmitters are fast becoming acceptance among the leading sound engineers, audio professionals and artists worldwide due to its innovative features, performance, reliability and cutting-edge technology not found on others.

MIPRO seeks Reproduction of the Natural Sound
Reproduction of the natural sound is MIPRO's design principle. ACT-707HM handheld transmitter features a hyper-cardioid directionality condenser capsule whose high fidelity, dynamic range, fast transient responses, low feedback howling and accurate sound image characteristics personify as such.

High SPL Inputs Without Distortion
The ACT-707HM unique high fidelity modulation circuit can sustain a maximum SPL of 142 dB over the full input frequency range of 50 Hz ~ 15 KHz (+1 ~ -3 dB) while the THD is still under 0.9% linear width.

Furthermore, since the sensitivity of the modulation circuitry is preset to accurately match the sensitivity of the capsule, users are no longer required to adjust the sensitivity level of their wireless microphone to obtain the optimal output level and dynamic range. This technology gives a clear and powerful performance in the high frequency range without having to reduce the volume to avoid distortion, unlike many other manufacturer's designs.

Innovative ACT Function Replaces Traditional Manual Adjustment
ACT-707HM utilizes the UHF band and is PLL synthesized. A conventional PLL transmitter's frequency is set up manually. This can be complicated as well as prone to errors. In order to avoid these problems, MIPRO has designed and introduced the patented ACT function to replace conventional manual adjustments. These user-friendly systems work with just one press of the receiver's SCAN button to automatically, rapidly, and accurately set and lock the receiver's working frequency. This quick and accurate set-up avoids the mistakes so often seen in manually adjusted systems.

High-Efficiency Circuitry And Sophisticated PCB Design
Inside the ACT-707HM, there is a high-efficiency, low-spurious emission, low-power-consumption circuit which gives you a truly impressive 18 hours of operation using just 2 AA batteries. Expertise in wireless design and many years of wireless know-how can be easily seen in the precise circuit layout of the ACT-707HM.

Standard Body Pack Transmitter

• Plastic Housing
• LED indicator displays power on/off and battery status

• Compact, lightweight and streamline shape for easy wearing.
• Impedance selectable switch for microphone or guitar, and built-in sensitivity level adjustor.
• Industry standard mini-XLR 4-pin (TA4F) connector is utilized for quick and screw lock connection and accepts lavaliere, headworn microphone and guitar inputs with level adjustments.
• Belt clip allows 360 degrees rotating to suit transmitter wearing.
• World's first ACT (Automatic Channel Targeting) function provides rapid automatic channel setting.
• Innovative "Photo-cell Coupling" high dynamic range and high fidelity modulation circuitry is capable of accepting high input level and less distortion.
• Advanced efficient transmitting and low power consumption circuit design provides battery operating hours 2~3 times longer than other brands.

Premium Body Pack Transmitter

• Plastic Housing
• LCD panel displays group, channel, error code, and battery fuel gauge simultaneously.
• Compact, lightweight and streamline shape for easy wearing.
• Impedance selectable switch for microphone or guitar, and built-in sensitivity level adjustor.
• Industry standard mini-XLR 4-pin (TA4F) connector is utilized for quick and screw lock connection and accepts lavaliere, headworn microphone and guitar inputs with level adjustments.
• Belt clip allows 360 degrees rotating to suit transmitter wearing.
• World's first ACT (Automatic Channel Targeting) function provides rapid automatic channel setting.
• Innovative "Photo-cell Coupling" high dynamic range and high fidelity modulation circuitry is capable of accepting high input level and less distortion.
• Advanced efficient transmitting and low power consumption circuit design provides battery operating hours 2~3 times longer than other brands.
• Professional quality ensures no impact-damage.

Professional Body Pack Transmitter

• Magnesium alloy housing.
• LCD panel displays group, channel, error code, and battery fuel gauge simultaneously.
• Compact, lightweight and streamline shape for easy wearing.
• Impedance selectable switch for microphone or guitar, and built-in sensitivity level adjustor.
• Industry standard mini-XLR 4-pin (TA4F) connector is utilized for quick and screw lock connection and accepts lavaliere, headworn microphone and guitar inputs with level adjustments.
• Belt clip allows 360 degrees rotating to suit transmitter wearing.
• World's first ACT (Automatic Channel Targeting) function provides rapid automatic channel setting.
• Innovative "Photo-cell Coupling" high dynamic range and high fidelity modulation circuitry is capable of accepting high input level and less distortion.
• Advanced efficient transmitting and low power consumption circuit design provides battery operating hours 2~3 times longer than other brands.
• Professional quality ensures no impact-damage.

Premium Uni-directional Lavalier Microphone

Miniature 10mmφ. High gain before feedback. Warm, clear sound

• Capsule Module(mm)：10mmΦ premium uni-directional miniature condenser microphone
• Frequency Response：50Hz~18KHz ± 3dB
• Capsule Impedance：200Ω
• Sensitivity ：-46dBV ± 3dBV/Pa (0dB=1V/Pa)
• Maximum SPL：142dB (Typical, 1%THD)。
• Capsule-shaft holder ：Dual - left and right side.
• Plug ：MIPRO's mini XLR 4 pin plug or TA4F
• Cable Length：150 cm
• Colour ：Black or Beige colour
• Weights(g) ：20

Omni-directional Lavalier Microphone

Sub-miniature 4.5mmφ. Low visibility.

• Capsule Module(mm)：10mmΦ premium uni-directional miniature condenser microphone
• Frequency Response：40Hz~20KHz ± 3dB
• Capsule Impedance：200Ω
• Sensitivity ：-49dBV±3dBV/Pa(0dB=1V/Pa)
• Maximum SPL：125dB (Typical, 1%THD)
• Capsule-shaft holder ：Dual - left and right side.
• Plug ：MIPRO's mini XLR 4 pin plug or TA4F
• Cable Length：150 cm
• Colour ：Black or Beige colour
• Weights(g) ：15

All Purpose Headworn Microphone

Premium Miniature Microphone

• Uni-directional pick-up pattern
• Visually unobtrusive and comfortable to wear.
• Flexible and durable frame with comfortable, soft ear hooks which require no adjustment for optimum comfort
• Interchangeable MU-53M uni-directional capsule module and MU-55M subminiature waterproof omni-directional capsule module.
• Featuring a high dynamic range and able to withstand a maximum SPL without distortion.
• Capsule module and cable are easily detached from the frame and can be worn on the left or right side of the frame to suit personal preferences.
• The very thin capsule-shaft mount is fully rotatable.
• The capsule-shaft allows for adjustments in length, direction and angle for precise and optimum capsule positioning in relation to the speakers mouth.
• Patented, swivelling earhook design allows for inward rotation, facilitating easy storage, packaging and carriage.
• Available in black and beige colours.
• Flexible gooseneck.
• Supplied as standard with MIPRO's mini XLR plug.
• Features a smooth, warm, natural sound.

Subminiture, Sweatproof, Microphone

• Designed for demanding live performance.
• Omni-directional pick-up pattern.
• Visually unobtrusive and comfortable to wear.
• Flexible and durable frame with comfortable, soft ear hooks which require no adjustment for optimum comfort
• Interchangeable MU-53M uni-directional capsule module and MU-55M subminiature waterproof omni-directional capsule module.
• Featuring a high dynamic range and able to withstand a maximum SPL without distortion.
• Capsule module and cable are easily detached from the frame and can be worn on the left or right side of the frame to suit personal preferences.
• The very thin capsule-shaft mount is fully rotatable.
• The capsule-shaft allows for adjustments in length, direction and angle for precise and optimum capsule positioning in relation to the speakers mouth.
• Patented, swivelling earhook design allows for inward rotation, facilitating easy storage, packaging and carriage.
• Available in black and beige colours.
• Flexible gooseneck.
• Supplied as standard with MIPRO's mini XLR plug.
• Features a smooth, warm, natural sound.

• Unobtrusive
• Isomax EarSets are by far the smallest, lightest and least visible headworn microphones.
• Conveniently Designed
• Wide Frequency Response
• Omnidirectional pick up pattern Clips directly to your ear. No conflict with hairstyles. No adjustment needed for the width of your head. The cable attaches with a quick connect connector for easy service.

• The E6 has the wide 50Hz to 20kHz response of a world class vocal microphone.
• Reduces Feedback
• Versatile
• Available for use with most wireless transmitters.
• Hard wired phantom power operation with adapter.
• Handles High Sound Levels
• Up to 145dB SPL

• Resistant to the sweat and moisture on stage

• Frequency Response:50Hz to 20kHz
• Operating Voltage:1 - 3.0 Volts
• Current Drain:320uA nominal
• Colours Available: Black, Light Beige, Cocoa.
